Thermal Imaging Cameras

Two Camera Technology

Thermal Imaging cameras are sophisticated pieces of equipment that are used by engineers to assist in identifying areas of heat waste or excessive temperatures.  Often used during building inspections to identify faults in thermal insulation or overheated industrial components or electrical and mechanical failures.  The colour map allows the user to view fast and accurate temperature measurements,



Thermal imager IR Thermometer
IRC130 Specifications
Thermal Imager

Designed with MSX technology that adds details to thermal images for greater clarity. Applications: Detect hot spots, avoid electrical and mechanical failures, locate water damage sources, find missing insulation and leaky air ducts, and troubleshoot automotive repair.

Thermal Imager IR Thermometer with MSX® IRC130


Two-camera technology: 80 x 60 true thermal imager, visual camera, plus coaxial laser


Built with dual visual and visual/thermal (MSX) cameras combined with an IR Thermometer, the IRC130 provides a whole picture of what the eye can’t see. Quickly locate potential issues using the unique coaxial distance-to-spot guidance laser. Store up to 50,000 JPEG files and easily transfer them via USB interface. Providing fast and accurate temperature measurements up to 1202°F (650°C), the IRC130 is a must-have diagnostic tool!




  • Large 2.4" TFT color display (320 x 240 pixels) with intuitive easy-to-navigate menu in 22 languages
  • Designed with integrated true thermal imager (80 x 60 pixels) to detect what the eyes can’t see
  • Patented MSX technology adds visible-light details to thermal images in real time for greater clarity without diluting the image or decreasing thermal transparency
  • Measure temperature up to 1202°F (650°C)
  • High accuracy with adjustable emissivity
  • Unique coaxial laser allows for locating hot or cold spots that may indicate potential issues
  • 30:1 distance-to-spot (target) ratio
  • Capture and store up to 50,000 MSX thermal and visual images in JPG format
  • USB interface for transferring images
  • Fast 150 ms response time for real-time temperature updates with continuous scanning
  • Bright LED flashlight
  • Standard UNC 1/4"-20 accessory mount
  • Rugged design with dust and water protection (IP54 rating) and 2-meter drop tested
  • Adjustable Auto Power Off (APO) timer
  • Low battery indicator
  • Complete with integrated 3.6 V rechargeable lithium ion battery, USB cable, lanyard, and pouch with convenient belt loop and shoulder strap
